UL3071 High-Temperature Silicone Wire
UL3071 high-temp hook-up wire with silver-plated copper and silicone insulation, rated 600V/200°C. Provides thermal endurance, stability, and flame resistance.
UL3071 High-Temperature Silicone Rubber Hook-Up Wire｜UL-Certified 200°C 600V Flexible Cable for Heating and Industrial Equipment
UL3071 is a high-temperature hook-up wire featuring solid or stranded silver-plated copper conductors with silicone rubber insulation. Rated for 600V and 200°C, it delivers excellent thermal endurance, electrical stability, and flame resistance in demanding environments.
Key Features of UL3071 Flexible Silicone Rubber Wire
- Conductor: Solid or Stranded Silver-Plated Copper
- Insulation: Silicone Rubber
- Rated Temperature: -60°C to +200°C
- Rated Voltage: 600V
- Flame Resistance: Passes Horizontal Flame Test; VW-1 available upon request
- Flexibility: Suitable for compact layouts and thermal cycling
- Compliance: RoHS and REACH compliant
Typical Applications for UL3071 200°C 600V Silicone Hook-Up Wire
- Internal wiring of heating systems and electric appliances
- Lead wires in high-temperature motors and transformers
- Internal cabling in industrial process equipment
- Control wiring in ovens, kilns, and thermal machinery
- High-temp instrumentation and power distribution circuits
Notes
UL3071 offers reliable insulation performance, flame resistance, and high thermal tolerance, making it suitable for high-stress environments in appliance manufacturing, thermal systems, and process automation. It is fully compliant with UL758 AWM Style 3071 standards.Related Links
- Explore UL3074 Silicone Wire (200°C, 600V)
- Explore UL3135 Silicone Wire (200°C, 600V)
Additional References
Need assistance selecting the right wire? Our technical team is ready to help you choose the best cable for your project.
